Black Red Colored Paint Protection Film

£103.00 GBP
In stock!
Size

View full details

Black Red Colored Paint Protection Film

Description

Features

  • Smooth, glossy, color shift finish.
  • Made from high-grade TPU material for premium protection.
  • Durable, high-performance, self-adhesive film.
  • Equipped with a heat-activated, self-healing topcoat.
  • Hydrophobic with UV and stain-resistant properties.
  • Offers supreme protection to the underlying surface
  • Scratch-resistant and anti-corrosion.
  • Heat and UV resistant.
  • Easy to apply and maintain.
  • Acrylic-based, robust adhesive.
  • Easy to slide and reposition.

 Specifications

  • Color: Black Red.
  • Finish: Color Shift.
  • Application Method: Wet Application
  • Packaging: Roll.
  • Sizes available: 5ft x 3.28ft. 10ft, 16ft, 33ft, and 49ft.

 Things You Should Know:

Best Paint Protection Film (PPF)

How To Apply Paint Protection Film

PPF Vs Vinyl Wrap

How Long Does Paint Protection Film Last?

How Much Does  Paint Protection Film Cost?

 Video

 Structure

Functions


Recommended Uses

▲ Standard Size & Appearance
Classification Unit Specs Remarks
Thickness Top protected film um 50±2% PET
Self-healing Layer um 15±2% /
Face Film um 160±8 Thermoplastic Polyurethane
Acrylic Adhesive um 25±2% Solvent-based
Release liner um 85±2% Satin Semi-transparent White
Surface － Glossy & Transparent Super Glossy without Orange Peel
Width m 1.52±0.01% 4.98ft
Length m 15±1% 49.21ft


Physical properties

▲ General Properties

Features Test Method/Conditions Data
Gloss（60°） GB 8807 ≥90
Water Contact Angle DL/T864 ≥75
Hardness ISO0868/ ASTM D-2240 ≥90
Elongation at Break GB/ T1040 ≥340
Coating Elongation at Break GB/ T1040 ≥85
Tensile Strength GB/ T1040 ≥20 (mpa)
Peel Strength GB/ T2792 ≥800
Scratch Repair (0.1mm) Copper brush & Heat gun Thermal Self-Healing
Chemical Resistance (Detergent) Naturally dried No Marks
Mud Resistance 70°/1h Wash & Heat gun No Marks
Stain Resistance (oil-based pen) Naturally dried, wipe with alcohol, no marks No Marks
Gloss 60° refraction ≥90°
Water Contact Angle Refer to DL/T864 ≥75°
Alkali Resistance (168H) 20% sodium hydroxide solution No abnormalities
Acid Resistance 10% hydrochloric acid solution No abnormalities
Yellowing ΔE QUV Method ≤2.4
Aging Test 1 70℃ and 7 days No Adhesive Residue with Heat
Aging Test 2 90℃ and 7 days No Adhesive Residue without Heat
Application Temperature / +20℃ to +30℃
Service Temperature / -50℃ to +110℃
Recommended Shelf Life 72°F (22°C) and 50% RH 2 years
Durability / 3 years



Recommendations

Recommended application tools: Squeegee, buffer, knife, masking tape, heat gun, magnets, gloves, IRR thermometer, sprayer, towel, and installation liquid
Application method: Standard methods for Paint Protection Film. Do not overstretch and overheat. Post-heating is necessary.
Post-heating temperature: 110°C flat surfaces, 130°C curves and overlaps.
Aftercare: PH neutral. Avoid wax or solvents.

CAUTION!

 1. We will peel off the protection layer before shipment if your order is 1m,3m or 5m in order to make the vinyl good for shipping.

 2. The images, colors, and finishes on the screen are approximate. For the real representation of the product always check the color swatch.
